NCP1342DADBDD1R2G is a quasi-resonant flyback controller launched by ON Semiconductor, specifically designed for high-performance offline power converters. The chip is packaged in a SOIC-9 package and is suitable for AC-DC power management. It features low no-load power consumption (<30mW) and high-efficiency conversion characteristics, and is widely used in fast-charging adapters, LED driver power supplies, industrial power supplies, and other fields.

Key Features Of NCP1342DADBDD1R2G

Quasi-resonant (QR) control: Optimises switching losses and improves efficiency by 6%.

Valley Lock Technology: Ensures stable valley switching and reduces EMI noise.

Ultra-low standby power consumption: <30mW (with integrated X2 capacitor discharge function).

Wide voltage input range: VCC supply 9V~28V, supporting global AC input.

Multiple protection mechanisms:

Overvoltage protection (OVP)

Overcurrent Protection (OCP)

Over-Temperature Protection (OTP)

Short-Circuit Protection (SCP)

Frequency Folding: Reduces switching frequency under light load conditions to improve efficiency.

Silent Skip Mode: Reduces audible noise under light load conditions.

NCP1342DADBDD1R2G Typical Applications

65W to 100W GaN fast-charging power supplies.

Laptop/tablet adapters.

LED driver power supplies & industrial switching power supplies.

Smart home & consumer electronics power management.

NCP1342DADBDD1R2G Packaging and Specifications

Product Type: Switching Controller

Topology: Flyback

Number of Outputs: 1 Output

Switching Frequency: 25 kHz

Output Voltage:    12 V

Output Current:    800 mA

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Mounting Style:    SMD/SMT

Package/Enclosure:    SOIC-9
