IMD112T-6F040 is highly integrated ICs for the control of variable speed drives. It integrates a motor controller with a high voltage three phase gate driver and a voltage regulator.

Feature

Motion Control Engine (MCE) as a ready-to-use control solution for variable speed drives

Integrated script engine for application control customization

Integrated drive and system protection features

Field oriented control (FOC) for permanent magnet synchronous motor (PMSM)

Flexible space vector PWM for sinusoidal voltage control

Current sensing via single or leg shunt

Sensorless operation

Hall sensor operation using analog or digital Hall

Integrated analog comparators for over-current protection

Built-in temperature sensor

Power factor correction (PFC) control (optional)

Flexible control input options: UART, Frequency, duty cycle or analog signal

Certified drive safety functions according to IEC/UL 60730-1 ‘Class B’

High voltage three phase gate driver with 600 V blocking voltage

15V supply voltage for gate driver

Thin-film-SOI-technology with negative transient robustness

Ultra fast integrated boot strap diodes

Integrated 5 V voltage regulator for controller supply

External 5 V output available

Small LQFP-40 package with improved clearance & creepage

Footprint derived from LQFP-48

Applications

Small and major home appliances

Fans, Pumps, Compressors

General purpose variable speed drives
