The ADG5419BCPZ is a single-chip industrial CMOS analogue switch with a built-in latch-up-proof single-pole-double-throw (SPDT) switch.The LFCSP-packaged device provides an EN input to enable or disable the device. When disabled, all channels are turned off.

Product Attributes

Switching Circuits: SPDT

Multiplexer/Demultiplexer Circuit: 2:1

Number of circuits: 1

On-resistance (max): 14 ohms

Channel to Channel Matching (ΔRon): 100 milliohms

Voltage - Supply, Single (V+): 9V ~ 40V

Voltage - Supply, Dual (V±): ±9V ~ 22V

Switching Time (Ton, Toff) (Max): 239ns, 185ns

-3db Bandwidth: 190MHz

Charge Injection: 160pC

Channel Capacitance (CS(off), CD(off)): 11pF, 22pF

Current - Leakage (IS(off)) (max): 250pA

Crosstalk: -80dB @ 1MHz

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Shell: 8-WFDFN Exposed Pad, CSP

Supplier Device Package: 8-LFCSP-WD (2x3)

Applications

High Voltage Signal Routing

Automated Test Equipment

High Voltage Signal Routing

Analogue front-end circuits

Precision Data Acquisition Systems

Industrial Instrumentation

Amplifier Gain Selection
