Service Telephone:86-755-83294757
Trade Name:Digital Potentiometer
Brand:ADI
Particular Year:22+
Package:TSSOP-20
Delivery Date:New and Original
Stock: 2000pcs
The AD5254BRUZ50 is a dual-channel, 256-bit, I2C, non-volatile memory, digital potentiometer. It provides electronic adjustment functionality equivalent to mechanical potentiometers, adjusters, and variable resistors. The device's versatile programming capabilities support multiple operating modes, including read/write access to RDAC and EEMEM registers, resistor increment/decrement, ±6 dB resistor range changes, and cursor setting readback. Additionally, it offers extra EEMEM for storing user-defined information such as memory data from other components, lookup tables, or system identification information.
The AD5254BRUZ50 allows the master I2C controller to write any 64/256-step cursor settings to the RDAC registers and store them in EEMEM. After storage, these settings are automatically restored to the RDAC registers at system power-up; they can also be dynamically restored.
The AD5254BRUZ50 provides additional increment, decrement, and ±6 dB step changes in synchronous or asynchronous channel update modes. The increment and decrement functions support stepwise linear adjustment, while the ±6 dB step changes are equivalent to doubling or halving the RDAC cursor setting. These functions are suitable for steep slope adjustments, non-linear adjustments such as white LED brightness, and volume control.
The AD5254BRUZ50 features a patented resistor tolerance storage function, allowing users to access the EEMEM and obtain the end-to-end absolute resistance values of the RDAC for precision applications.
AD5254BRUZ50 Features
Dual-channel 256-bit resolution
1 kΩ, 10 kΩ, 50 kΩ, 100 kΩ
Non-volatile memory stores cursor settings with write protection
EEMEM settings refreshed within 300 µs (typical) at power-up
EEMEM rewrite time = 540 µs (typical)
Resistance tolerance stored in non-volatile memory
12 additional bytes stored in EEMEM for user-defined information
I2C-compatible serial interface
Direct read/write access to RDAC and EEMEM registers
Predefined linear increment/decrement commands
Predefined ±6 dB step change commands
Synchronous or asynchronous dual-channel updates
Cursor setting readback functionality
4 MHz bandwidth — 1 kΩ version
Single-supply operation: 2.7 V to 5.5 V
Dual power supply: ±2.25 V to ±2.75 V
2 slave address decoding bits support operation of 4 devices
100-year typical data retention period, TA = 55°C
Operating temperature: -40°C to +105°C
Applications of AD5254BRUZ50
Replacement for mechanical potentiometers
General-purpose DAC replacement
LCD panel VCOM adjustment
White LED brightness adjustment
RF base station power amplifier bias control
Programmable gain and offset control
Programmable voltage-to-current conversion
Programmable power supply
Sensor calibration
