The LTC1668IG is a 16-bit, 50Msps differential current output DAC, implemented using a high-performance BiCMOS process and featuring laser-trimmed thin-film resistors. The combination of a novel current-steering architecture and a high-performance process results in a DAC with outstanding AC and DC performance. The LTC1668IG is the first 16-bit DAC on the market to achieve 87dB SFDR (Spurious-Free Dynamic Range) at an output signal frequency of 1MHz.

The LTC1668IG operates on ±5V power supplies and can be configured to provide up to 10mA of full-scale output current. The differential current output of these DACs enables single-ended or true differential operation. The LTC1668IG's –1V to 1V output compliance allows the output to be directly connected to an external resistor to generate a differential output voltage without compromising the converter's linearity. Alternatively, the output can be connected to the summing node of a high-speed operational amplifier or connected to a transformer.

The LTC1668IG is a pin-compatible device, available in a 28-pin SSOP package, and fully specified for operation over the industrial temperature range.

Features (LTC1668IG)

50 Msps update rate

Pin-compatible with 12-bit, 14-bit, and 16-bit devices

High spectral purity: 87 dB SFDR at 1 MHz fOUT

5 pV-s glitch noise pulse

Differential current output

20 ns stabilisation time

Low power: 180 mW (using ±5V power supply)

TTL/CMOS (3.3V or 5V) inputs

Small package: 28-pin SSOP

Applications (LTC1668IG)

Cellular base stations

Multi-carrier base stations

Wireless communications

Direct Digital Synthesis (DDS)

xDSL modems

Arbitrary waveform generation

Automated test equipment

Instruments
