Trade Name:Voltage Reference
Brand:ADI
Particular Year:21+
Package:TSOT-23-6
Delivery Date:New and Original
Stock: 22300pcs
The LT6654AHS6-2.5 is a high-precision, low-noise, wide input voltage range 2.5V voltage reference chip packaged in a TSOT-23-6 package (3mm × 3mm). This device is suitable for applications requiring a high-stability reference voltage, such as precision measurement, data acquisition systems, industrial control, and automotive electronics.
LT6654AHS6-2.5 Key Features
High-Precision Output
Output Voltage: 2.5V, initial accuracy ±0.05%
Temperature Coefficient: 10 ppm/°C, ensuring high stability over a wide temperature range
Wide Input Voltage Range
3V to 36V (some models support 4.5V to 18V)
Suitable for 12V/24V industrial and automotive power systems
Low Noise & High PSRR
Noise (0.1Hz to 10Hz): 1.5μVpp
Ripple Suppression Ratio (PSRR) >80dB @ 100Hz to 100kHz
Low Power Consumption Design
Quiescent Current: 600μA (typical)
Suitable for battery-powered devices
High Drive Capability
Output Current: 10mA (maximum)
Supports ADC/DAC reference input, sensor bias
Automotive-grade reliability
Operating temperature: -40°C to +125°C
Compliant with AEC-Q100 standard (select models)
LT6654AHS6-2.5 Applications
Automotive control and monitoring
High-temperature industrial
High-resolution data acquisition systems
Instrumentation and process control
Precision voltage regulators
Medical equipment
Model
Brand
Package
Quantity
Describe
ADI
SOT-23-3
26500
2.5V ultra-low power consumption, precision series mode reference voltage source
ADI
MSOP-8
3000
An 8ppm/°C, 5V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
A reference voltage source of 8ppm/°C and 4.096V certified for automotive applications
ADI
MSOP-8
2500
An 8ppm/°C, 3.0V reference voltage source certified for automotive applications
ADI
MSOP-8
3000
An 8ppm/°C, 2.5V reference voltage source certified for automotive applications
ADI
SOT-23-6
3000
20ppm/°C precision, wide power supply range, high output drive, low noise reference
