The AWR2943ABGALTRQ1 is a single-chip millimetre-wave sensor consisting of an FMCW transceiver capable of operating in the 76GHz to 81GHz band, a radar data processing element, and an in-vehicle network peripheral. It is manufactured using TI's low-power 45nm RFCMOS process and offers excellent integration in a small package with ultra-low BOM count. It is an ideal solution for low-power, self-monitoring, ultra-accurate radar systems in the automotive sector.

Features

● FMCW transceiver

● Integrated PLL, transmitter, receiver, baseband, and ADCs

● 76GHz to 81GHz coverage with 5GHz available bandwidth

● 4 receive channels and 3 to 4 transmit channels with PCB antenna interface

● Per-transmit phase shifter

● Ultra-precise linear FM pulse engine based on fractional N PLLs

● TX power: 13.5dBm

● RX Noise Figure: 12dBm

● Phase noise at 1MHz:

-96dBc/Hz (76 to 77 GHz)

-95dBc/Hz (76 to 81 GHz)

Applications

● Lane Change Assist

● Blind Spot Detection

● Automatic Emergency Braking

● Adaptive Cruise Control

● Cross-traffic alert
