The VL53L4CXV0DH/1 is suitable for long-range multi-target measurements and offers very high distance accuracy at distances of up to 6m, with fairly accurate results at short distances. A new generation of laser emitters with an 18° field of view improves performance in ambient light.

All features

Fast, accurate distance measurement

Based on histogram technology

Measuring distances from 0 mm - 6 m

Linear short range down to 10 mm

Significantly improved long-range performance on all targets at all brightness levels

18° field of view (FoV)

Multi-target detection capability

Targets at distances greater than 80cm are unaffected by crosstalk caused by cover glass and smudges

The VL53L4CX is a fully integrated miniaturised module

Emitter: 940 nm invisible laser (VCSEL) and its analogue driver

Low-power microcontroller running advanced digital firmware

Dimensions: 4.4 x 2.4 x 1 mm

Pin compatible with VL53L0X, VL53L1X, VL53L1CB, VL53L3CX and VL53L4CD

Easy integration

Reflowable components

Real-time crosstalk correction

Inter-part or generic shape crosstalk calibration available

Single supply 2v8

Can be hidden behind cover tabs

I²C interface (up to 1 MHz)

Full set of software drivers (Linux compatible) for turnkey ranging

All drivers compatible with VL53L3CX

Applications

Obstacle avoidance and cliff detection for robots, service robots and hoovers

User presence detection for hygiene and smart lighting

System activation for smart building and access control devices

Smart bin and logistics content management

User and object detection for IoT devices

Light curtains for industrial applications

Landing assistance and collision avoidance for indoor drones
