Commodity Model:AWR2944ABGALTQ1

Trade Name:AWR2944ABGALTQ1

Data Manual:AWR2944ABGALTQ1.pdf

Brand:TI

Particular Year:23+

Package:SMD

Delivery Date:New and Original

Stock: 1000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
AWR2944ABGALTQ1
Package
SMD
Describe
Radar Sensor Sensor CAN, GPIO, I²C, LVDS, SPI, UART Outputs

Product Description

The AWR2944ABGALTQ1 76GHz to 81GHz FMCW radar sensor is a single-chip millimetre-wave sensor consisting of an FMCW transceiver capable of operating in the 76GHz to 81GHz band, a radar data processing element, and an in-vehicle network peripheral.The AWR294x is manufactured using TI''s low-power 45nm Manufactured on TI's low-power 45nm RFCMOS process and featuring excellent integration with ultra-low BOM counts in a small package, the AWR294x is an ideal solution for low-power, self-monitoring, ultra-accurate radar systems in the automotive space.


Features

● FMCW transceiver

● Integrated PLL, transmitter, receiver, baseband and ADC

● 76GHz to 81GHz coverage with 5GHz of available bandwidth

● 4 receive channels and 3 to 4 transmit channels with PCB antenna interface

● Per-transmit phase shifter

● Ultra-precise linear FM pulse engine based on fractional N-split PLLs

● TX power: 13.5dBm

● RX noise figure: 12dBm

● Phase noise at 1MHz: -96dBc/Hz (76GHz to 77GHz), -95dBc/Hz (76GHz to 81GHz)


Applications

● Lane Change Assist

● Blind Spot Detection

● Automatic Emergency Braking

● Adaptive Cruise Control

● Cross-traffic alert
