The AD4131-8BCBZ-RL7 is an ultra-low-power, high-precision measurement solution for applications that operate with low-bandwidth batteries. The fully integrated analog front end (AFE) includes multiplexers for up to 16 single-ended or 8 differential inputs, programmable gain amplifiers (PGA), 16-bit sigma-δ analog-to-digital converters (ADCs), on-chip reference voltage sources and oscillator, optional filter options, intelligent timing controllers, sensor bias and excitation options, diagnostics, and control Space ratio.

specification

Number of digits: 16

Sampling rate (per second) : 2.4k

Input number: 16

Input type: differential, pseudo-differential, single-ended

Data interface: SPI

Configuration: MUX-PGA-ADC

Ratio -S /H:ADC: 0:1

Number of A/D converters: 1

Architecture: trigonometric integration

Reference type: External, internal

Voltage - power supply, analog: 1.71V ~ 3.6V

Voltage - power supply, number: 1.65V ~ 3.6V

Features: PGA, synchronous sampling, temperature sensor

Operating temperature: -40°C ~ 105°C

Package/housing: 35-UFBGA, WLCSP

Supplier Package: 35-WLCSP (2.7x3.56)

Mounting type: Surface mount type
