Trade Name:AD5322ARMZ
Data Manual:AD5322ARMZ.pdf
Brand:ADI
Particular Year:23+
Package:MSOP-10
Delivery Date:New and Original
Stock: 4300pcs
The AD5322ARMZ is a dual-channel, 12-bit, buffered voltage output DAC available in a 10-pin µSOIC package and powered from a single +2.5 V to +5.5 V supply with 230 µA at 3 V. The device has a built-in, on-chip output amplifier capable of delivering a rail-to-rail output swing with a slew rate of 0.7 V/µs. The AD5322ARMZ features a versatile three-wire The AD5322ARMZ features a versatile three-wire serial interface capable of operating at clock rates up to 30 MHz and is compatible with standard SPI™, QSPI™, MICROWIRE™, and DSP interface standards.
Benefits and Features
Two 12-bit DACs in one package
Micropower consumption: 300 µA (5 V, including reference current)
Power saving mode: 200 nA (5 V), 50 nA (3 V)
Monotonicity guaranteed by design
Power-on reset to 0 V
Selectable buffered/unbuffered reference voltage input
Output voltage: 0-VREF
Low power, SPI™, QSPI™, MICROWIRE™, DSP-compatible 3-wire serial interface
Output buffer amplifier with rail-to-rail operation
Simultaneous update of DAC outputs via LDAC pin (active low)
Temperature range: -40ºC to 105ºC
Three shutdown functions
Applications
Portable battery-powered instruments
Digital gain and offset adjustment
Programmable voltage and current sources
Programmable attenuators
