The VN7050ASTR, manufactured using STMicroelectronics' proprietary VIPower M0-7 technology, is a single-channel high-side driver housed in an SO-8 package. This device is designed to drive 12V automotive ground loads via 3V and 5V CMOS-compatible interfaces, while providing protection and diagnostic features.

The device incorporates advanced protection features including load current limiting, active overload management via power limiting, and over-temperature shutdown with configurable latch-off capability.

A fault reset pin can release output latching during faults or disable the latch-off function.

A dedicated, multi-purpose multiplexed analogue output pin provides precision diagnostics. Beyond detecting overloads, ground shorts, VCC shorts, and open-load conditions during shutdown, it supports high-accuracy proportional load current sensing, supply voltage feedback, and chip temperature monitoring.

The detection enable pin disables shutdown diagnostics during the module's low-power mode and facilitates sharing of external detection resistors between identical devices.

VN7050ASTR Product Attributes

Manufacturer: STMicroelectronics

Series: VIPower™

Switch Type: Universal

Number of Outputs: 1

Ratio - Input:Output: 1:1

Output Configuration: High-side

Output Type: N-channel

Interface: On/Off

Voltage - Load: 4V to 28V

Voltage - Supply (Vcc/Vdd): Not required

Current - Output (Max): 21A

On-Resistance (Typical): 50 mΩ

Input Type: Non-inverting

Features: Auto-restart, Status flag

Fault Protection: Current limiting (fixed), Open-load detection, Over-temperature, Over-voltage, UVLO

Operating Temperature: -40°C to 150°C (TJ)

Mounting Type: Surface Mount

Supplier Device Package: 8-SOIC

VN7050ASTR Applications

• Suitable for various automotive resistive, inductive, and capacitive loads

• Specifically designed for automotive turn indicators (supporting P27W/SAE1156 specifications or LED rear combination lamps)

• Provides protected power supply for ADAS systems: radar and sensors
