The L6599ADTR is an enhanced version of its predecessor, the L6599, serving as a dual-ended controller specifically designed for series resonant half-bridge topologies. It provides a 50% complementary duty cycle: the high-side and low-side switches are driven to turn on/off with an 180° phase difference, whilst maintaining identical on-time durations. Output voltage regulation is achieved by adjusting the operating frequency. A fixed dead time inserted between the turn-off and turn-on of both switches ensures soft switching and enables high-frequency operation.

To drive the upper switch using a bootstrap configuration, the IC incorporates a high-voltage floating structure capable of withstanding voltages exceeding 600V. Its synchronously driven high-voltage DMOS replaces the need for an external fast-recovery bootstrap diode.

The IC supports setting the converter's operating frequency range via an external programmable oscillator.

L6599ADTR Features

50% duty cycle resonant half-bridge variable frequency control

High-precision oscillator

Maximum operating frequency of 500kHz

Dual-stage overcurrent protection: frequency shift and latch-off shutdown

Supports PFC controller interface

Latch-type disable input

Burst mode operation supported at light loads

Power-up sequence/undervoltage protection input

Non-linear soft-start for monotonic output voltage rise

High-side gate driver compatible with 600V power rails, featuring integrated bootstrap diode and high dv/dt immunity

-300/800 mA high-side/low-side gate drivers with undervoltage lockout pull-down

L6599ADTR Specifications

Topology:    Half Bridge

Number of Outputs:    1 Output

Switching Frequency:    500 kHz

Duty Cycle - Maximum:    52 %

Output Voltage:    13.3 V

Output Current:    800 mA

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +150°C

Package: 16-SO

L6599ADTR Applications

LCD and PDP televisions

Desktop computers, entry-level servers

Telecom switching power supplies

High-efficiency industrial switching power supplies

AC-DC adapters, open-frame switching power supplies
