The VND5E012MYTR is a dual-channel high-end driver manufactured with STMicroelectronics VIPower M0-5 technology in a small PowerSSO-36 package. The VND5E012MYTR is designed to drive a 12V automotive ground load, providing protection, diagnostics, and 3V and 5V CMOS compatible interfaces with any microcontroller.

The VND5E012MYTR integrates advanced protection functions, such as load current limiting, active surge and overload management through power limiting, automatic restart over-temperature shutdown, and active overvoltage clamping.

Core parameters

Switch type: Universal

Output number: 2

Ratio - Input: Output: 1:1

Output configuration: High-end

Output type: N-channel

Interface: On/Off

Voltage - Load: 4.5V to 28V

Voltage - Power supply (Vcc/Vdd) : Not required

Current - Output (maximum) : 52A

On-resistance (typical value) : 11 milliohms

Input type: Non-inverting

Feature: Equipped with an automatic restart function

Fault protection: Current limiting (fixed), over-temperature, over-voltage

Operating temperature: -40°C to 150°C (TJ)

Grade: Automotive grade

Qualification: AEC-Q100

Installation type: Surface mount type

Device packaging: PowerSSO-36

Application scenarios

The VND5E012MYTR driver is suitable for industrial or automotive electronics fields such as power management and load driving that require high current output.
