UCC27301AQDDARQ1: Automotive-grade 120V, 4A half-bridge driver, VQFN-40

Model: UCC27301AQDDARQ1

Package: VQFN-40

Type: Half-Bridge Driver

Overview: The UCC27301AQDDARQ1 is a robust gate driver designed to drive two N-channel MOSFETs in a half-bridge or synchronous buck configuration, with an absolute maximum bootstrap voltage of 120V.

UCC27301AQDDARQ1 Product Features:

Drives two N-channel MOSFETs in a half-bridge configuration

-40°C to +150°C junction temperature range

120V absolute maximum voltage on HB pin

3.7A sink current, 4.5A source current output

8V to 17V VDD operating range (20V absolute maximum) with UVLO functionality

-(28-VDD)V absolute maximum negative transient tolerance on HS pin (< 100ns pulse)

-10V to +20V absolute maximum input pin tolerance, independent of supply voltage range (TTL compatible)

Switching Parameters:

20ns typical propagation delay time

7.2ns rise time and 5.5ns fall time with 1000pF load

4ns typical delay matching

Integrated bootstrap diode

Input interlock

Enable/disable function with low current consumption when disabled (typically 3µA) (DRC package only)

UCC27301AQDDARQ1 Applications:

Automotive DC/DC converters and OBCs

Two-wheeler/three-wheeler traction drives and battery packs

Electric power steering (EPS)

Wireless charging

Smart glass modules
