The L99MD01XPTR is an octal half-bridge driver for automotive applications.
The L99MD01XPTR device is used to drive DC and/or stepper motors. Four stepper motors can be driven simultaneously using the boost converter. Without the boost converter, the system can run 3 stepper motors in sequential mode or 2 stepper motors simultaneously. The octal half-bridge configuration can also drive 4 DC motors simultaneously or 7 DC motors sequentially.
An integrated 24-bit standard serial peripheral interface (SPI) controls all outputs and provides diagnostic information: normal operation, open load, overcurrent, temperature warning, and overtemperature.
Features of the L99MD01XPTR
8 half-bridges
RON = typ. 0.9 Ω (HS), 0.64 Ω (LS) @ Tj = 25 °C
Current limit of 0.8 A minimum per output
Built-in DC/DC boost converter driving external MOSFETs
PWM mode selectable on all half-bridges for current holding
Internal PWM generator
Two current monitoring outputs
SPI interface for data communication
Temperature warning
All outputs are over temperature protected
Short-circuit protection on all outputs
VCC supply voltage 3.0 to 5.3 V
Very low current consumption in standby mode, 5 µA typical
VS compliant Operating range: 6 V to 18 V
L99MD01XPTR Product Attributes
Manufacturer: STMicroelectronics
Product Category: Motor/Motion/Ignition Controllers and Drivers
Type: Half Bridge
Output Current: 250 mA
Operating supply current: 4.2 mA
Minimum operating temperature: - 40 C
Maximum operating temperature: + 150 C
Mounting Style: SMD/SMT
Package / Case: PowerSSO-36
Qualification: AEC-Q100
Humidity Sensitivity: Yes
Series: L99MD01
Applications for L99MD01XPTR
Stepper motor drivers and/or DC
To drive HVAC baffles
Model
Brand
Package
Quantity
Describe
INFINEON
TO263-7
10000
High-performance half-bridge driver chips, part of the NovalithIC™ family
Maxim
12-FC2QFN
1000
Half Bridge Driver Synchronous Buck Converter 12-FC2QFN (3.25x7.4)
Maxim
12-FC2QFN
1000
Half Bridge Driver Synchronous Buck Converter 12-FC2QFN (3.25x7.4)
Maxim
12-FC2QFN
1000
Half Bridge Driver Synchronous Buck Converter 12-FC2QFN (3.25x7.4)
Maxim
12-FC2QFN
1000
Half Bridge Driver Synchronous Buck Converter 12-FC2QFN (3.25x7.4)
Renesas
QFN
21000
Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors
