The L6201PSTR is a full-bridge driver for motor control applications that uses Multipower-BCD technology to combine isolated DMOS power transistors, CMOS and bipolar circuits on the same chip. By using hybrid technology, the logic circuits and power stages can be optimised for best performance, and the DMOS output transistors can operate at supply voltages up to 42V and operate efficiently at high switching speeds. All logic inputs are TTL, CMOS, and µC compatible. each channel (half-bridge) of the device is controlled by a separate logic input, while both channels are controlled by a common enable. i.c. is mounted in three different packages.

All Features

High efficiency

Internal logic power supply

Operating frequency up to 100 KHz

TTL compatible driver

Supply voltage up to 48V

Total RMS current up to: L6201: 1A; L6202: 1.5A; L6203/L6201PS: 4A

5A max peak current (L6201 2A max)

Cross conduction protection

Thermal shutdown

RDS (ON) = 0.3 Ω (typical at 25°C)

Product Attributes - L6201PSTR

Product Category: Motor/Motion/Ignition Controllers and Drivers

Product: Brushed DC Motor Drivers

Type: Full Bridge

Output Current: 2 A

Operating supply current: 15 mA

Minimum operating temperature: - 40 C

Maximum operating temperature: + 150 C

Mounting Style: SMD/SMT

Package / Case: PowerSO-20

Supply Voltage - Max: 48 V

Supply Voltage - Min: 12 V
