The DAC128S085CIMTX is a 12-bit, ultra-low-power, eight-channel digital-to-analogue converter (DAC) featuring rail-to-rail output capability. It supports a wide supply voltage range from 2.7V to 5.5V, with power consumption of just 1.95 milliwatts at 3V and 4.85 milliwatts at 5V. Housed in a 16-pin TSSOP package, the device offers a flexible serial interface compatible with standards such as SPI, QSPI, and MICROWIRE.

Core Features of DAC128S085CIMTX

High Resolution and Accuracy: 12-bit resolution, INL ±8 LSB (maximum), DNL 0.75/-0.4 LSB (maximum).

Low-power design: Typical power consumption as low as 1.95 milliwatts (3V) and 4.85 milliwatts (5V), with power-down mode consumption as low as 0.3 microwatts (3V)/1 microwatt (5V).

Rail-to-rail output: On-chip output amplifier supports rail-to-rail voltage output, providing an output range from 0V to VA.

Flexible serial interface: Supports clock rates up to 40MHz, compatible with SPI, QSPI, MICROWIRE, and DSP interfaces.

Power-on reset function: Ensures DAC outputs initialise to zero volts upon power-up.

Independent power-down capability: Each DAC channel can be individually powered down to reduce power consumption.

Wide operating temperature range: -40°C to +125°C.

DAC128S085CIMTX Specifications

Product Type: Digital-to-Analogue Converter - DAC

Series: DAC128S085

Resolution: 12 bits

Interface Type: 3-Wire, DSP, Microwire, QSPI, SPI

Minimum Operating Temperature: -40°C

Maximum Operating Temperature: +125°C

Mounting Style:    SMD/SMT

Package / Case:    TSSOP-16

Features:    Cost-optimised, low power consumption, synchronous digital output, compact size

Gain Error:    1 % FSR

Power Consumption:    1.95 mW

Product Applications

The DAC128S085CIMTX is suitable for various applications requiring high precision, low power consumption and fast response, including:

Battery-powered devices

Digital gain and offset adjustment

Programmable voltage and current sources

Voltage reference for ADCs

Sensor supply voltage

Range detectors
