Texas Instruments' (TI) BQ7694202PFBR is a highly integrated, high-precision battery monitor and protector for 3- to 10-cell series lithium-ion, lithium-polymer, and lithium iron phosphate battery packs. The device incorporates a high-precision monitoring system and a highly configurable protection subsystem, supporting either autonomous or host-controlled battery balancing. It integrates a high-side charge pump NFET driver, dual programmable LDOs for external systems, and a host communication peripheral supporting 400kHz I²C, SPI, and HDQ single-wire protocols. The BQ7694202PFBR is available in a 48-pin TQFP package.

Features of the BQ7694202PFBR

• Battery monitoring functionality for 3 to 10 series-connected cells

• Integrated charge pump for high-side NFET protection with optional auto-recovery

• Comprehensive protection suite including voltage, temperature, current, and internal diagnostics

• Two independent ADCs

– Supports simultaneous current and voltage sampling

– High-precision coulomb counter with input offset voltage error < 1µV (typical)

– High-accuracy battery voltage measurement < 10mV (typical)

• Wide-range current applications (±200mV measurement range across sense resistor)

• Integrated chemical fuse driving secondary protection

• Autonomous or host-controlled battery balancing

• Multiple power modes (typical battery pack operating range conditions)

– Normal mode: 286µA

– Multiple sleep mode options: 24µA to 41µA

– Multiple deep sleep mode options: 9µA to 10µA

– Shutdown mode: 1µA

• 85V high-voltage tolerance on battery connections and select other pins

• Supports random battery connection sequences on production lines

• Temperature sensing via internal sensor and up to nine external thermistors

• Integrated one-time programmable (OTP) memory programmable by customer on production line

• Communication options include 400kHz I²C, SPI, and HDQ single-wire interface

• Dual programmable LDOs for external systems

• 48-pin TQFP package (PFB)

Applications for the BQ7694202PFBR

• Cordless power tools and garden tools

• Vacuum cleaners

• Electric bicycles, electric scooters and LEVs

• Non-military drones

• Other industrial battery packs (3 to 10 cells in series)
