The ADS7952SBDBTR is a 12-bit, 1 MSPS (million samples per second) analogue-to-digital converter (ADC) employing a SAR (Successive Approximation Register) architecture. It features 12 single-ended input channels supporting single-ended inputs. Designed for low-power applications, this chip consumes a typical power of just 11.5 mW and incorporates a power-down mode with a low power-down current of 1 µA.

ADS7952SBDBTR Specifications

Resolution: 12 bits

Maximum sampling rate: 1 MSPS

Number of input channels: 12 channels

Data interface: SPI

Architecture: SAR

Input Type: Single-ended

Multi-channel Configuration: Multiplexed

Reference Mode: External

Input Voltage Range: 0 to 5.25V

Operating Temperature Range: -40°C to 125°C

Typical Power Consumption: 11.5 mW

Analogue Supply Voltage Range: 2.7V to 5.25V

Digital Supply Voltage Range: 1.7V to 5.25V

Signal-to-Noise Ratio (SNR): 71.7 dB

Package Type: 38-pin TSSOP

Mounting Type: Surface Mount

ADS7952SBDBTR Features

• High-speed sampling rate: 1 MHz sampling rate, suitable for rapid data acquisition.

• Low-power design: Typical power consumption as low as 11.5 mW, ideal for battery-powered and isolated power supply applications.

• Wide analogue supply range: 2.7V to 5.25V, accommodating diverse power environments.

• Wide I/O supply range: 1.7V to 5.25V, offering flexible power selection.

• Two software-selectable input ranges: 0 to VREF and 0 to 2 x VREF, providing flexible input configuration.

• Automatic and manual modes: Supports channel selection in automatic and manual modes.

• Programmable alarm levels: Two programmable alarm levels per channel for convenient status monitoring.

• GPIO configuration: Four independently configurable GPIOs in TSSOP package; one GPIO in VQFN package.

• High input bandwidth: Input bandwidth up to 47 MHz (at 3 dB).

ADS7952SBDBTR Applications

• PLC/IPC

• Optical line card monitoring

• Medical instrumentation

• Digital power supplies

• Multi-channel general-purpose signal monitoring

• High-speed data acquisition systems

• High-speed closed-loop systems
