The MPQ2166GDE-AEC1-Z is a dual-channel PWM synchronous buck regulator with integrated internal compensation, operating over an input voltage range of 2.7V to 6V and delivering an output voltage as low as 0.6V. The MPQ2166GDE-AEC1-Z can be configured as either a 2A/2A or 3A/1A output current regulator, featuring a low quiescent current of 60µA, making it an ideal choice for portable products powered by a single lithium-ion (Li+) battery.

The MPQ2166GDE-AEC1-Z integrates dual 55mΩ upper transistors and 20mΩ synchronous rectifier transistors, eliminating the need for external Schottky diodes, thereby improving efficiency. The MPQ2166GDE-AEC1-Z features peak current control mode and internal compensation functionality, along with low dropout configuration capability. Both channels can operate at 100% duty cycle. Comprehensive protection features include cycle-by-cycle current limit protection and over-temperature shutdown protection.

MPQ2166GDE-AEC1-Z Product Features and Advantages

Operating input voltage range: 2.7V to 6V

2A/2A or 3A/1A continuous current

55mΩ/20mΩ on-resistance

Programmable frequency up to 3MHz

External synchronisation clock frequency up to 3MHz

180° phase-shifted control mode

Power good output indication (PG)

External soft-start (SS) and tracking functionality

Adjustable advanced asynchronous mode (AAM) or forced continuous conduction mode (FCCM)

Peak efficiency >90%

Output regulation range from 0.6V to VIN

Supports 100% duty cycle

MPQ2166GDE-AEC1-Z Product Attributes

Product Type: Switching Regulator

Mounting Style: SMD/SMT

Package/Case: QFN-18

Topology: Buck

Output Voltage: 600 mV to 5.5 V

Output Current:    3 A

Number of Outputs:    2 Outputs

Input Voltage - Minimum:    2.7 V

Input Voltage - Maximum:    6 V

Quiescent Current:    60 uA

Switching Frequency:    3 MHz

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Qualification:    AEC-Q100

Series:    MPQ2166G

Input Voltage:    2.7 V to 6 V
