Commodity Model:ADG1401BRMZ

Trade Name:Analogue Switch IC

Brand:ADI

Particular Year:22+

Package:MSOP-8

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADG1401BRMZ
Package
MSOP-8
Describe
1 Ω on-resistance, ±15 V/+12 V/±5 V, iCMOS single-pole single-throw switch

Product Description

The ADG1401BRMZ is a high-performance single-pole single-throw (SPST) analogue switch in an 8-MSOP (3.00 mm wide) package. The chip features low on-resistance (1.3 Ω) and fast switching time (150 ns), making it suitable for applications such as signal routing, data acquisition, and audio/video switching.


ADG1401BRMZ Product Features

On-resistance: 1 Ω

On-resistance flatness: 0.2 Ω

Continuous current up to 435 mA

Rated supply voltage: +12 V, ±15 V, ±5 V

No VL power supply required

3 V logic-compatible input

Rail-to-rail operation


ADG1401BRMZ Product Parameters

Product Type:    Analogue Switch IC

Mounting Style:    SMD/SMT

Package/Case:    MSOP-8

Number of Channels:    1 Channel

Configuration:    1 x SPST

On-Resistance—Maximum:    1.3 Ohms

Supply Voltage—Minimum:    5 V

Supply Voltage—Maximum:    16.5 V

Minimum Dual Supply Voltage:    +/- 5 V

Maximum Dual Supply Voltage:    +/- 16.5 V

Operating Time—Maximum:    150 ns

Idle Time—Maximum:    150 ns

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +125°C

Series:    ADG1401

Pd-Power Dissipation:    1.44 mW


ADG1401BRMZ Product Applications

Automatic Test Equipment

Data Acquisition Systems

Battery-Powered Systems

Sample-and-Hold Systems

Audio Signal Routing

Video Signal Routing

Communication Systems

Relay Replacement Solutions

Associated Products

Model

Brand

Package

Quantity

Describe

ADG1612BRUZ

ADI

TSSOP16

5000

1 Ω typical on-resistance, ±5 V, +12 V, +5 V, and +3.3 V four-channel SPST switch

ADG849YKSZ

ADI

SC70-6

12000

3 V/5 V CMOS 0.5 Ω single-pole, double-throw switch in SC70 package

ADGS5412BCPZ

ADI

LFCSP-24

3000

Four-channel SPST switch with serial control, high voltage anti-latch type

ADGS1412BCPZ

ADI

LFCSP-24

2500

SPI interface, 1.5Ω RON, ± 15V /+ 12V, four-channel SPST switch

ADG5436FBCPZ

ADI

LFCSP-16

3000

Fault protection and detection, 10 Ω RON, dual channel SPDT switch

ADG5436BRUZ

ADI

TSSOP-16

3000

High voltage anti-latch type dual channel SPDT switch

ADG5413BFBCPZ

ADI

LFCSP-16

2500

Bidirectional fault protection and detection, 10 Ω RON, four-channel single-pole single-throw switch

ADG5412FBCPZ

ADI

LFCSP-16

3000

Fault protection and detection, 10 Ω RON, four-channel single-pole single-throw switch

ADG1213YCPZ

ADI

LFCSP-16

3000

Low capacitance, low charge injection, ±15 V/+12 V iCMOS, four-channel single-pole single-throw switch

ADG5434BCPZ

ADI

LFCSP-20

2500

High voltage anti-latch type four-channel SPDT switch
