The ADG849YKSZ is a single-chip CMOS single-pole, double-throw (SPDT) switch powered from a +1.8 V to 5.5 V supply. It has an ultra-low on-resistance of 0.5 Ω typical, making it ideal for applications requiring very low switching distortion, and the ADG849YKSZ is also capable of carrying large amounts of current; 600 mA typical with a 5 V supply.

When switched on, each switch of the ADG849YKSZ has the same conductivity in both directions. The device is an open-then-close type, which prevents transient short circuits when switching channels.

The ADG849YKSZ is available in a small 6-pin SC70 package, making it ideal for space-constrained applications.

ADG849YKSZ Product Features

Ultra-low on-resistance:

0.5 Ω (typical)

Less than 0.8 Ω (maximum, 5 V supply)

Excellent distortion performance:

0.01 Ω (typical)

0.2 Ω (maximum, on-resistance RON flatness)

Single supply: +1.8 V to +5.5 V

High current-carrying capacity.

400mA (continuous current)

600mA (peak current, 5V)

Extended temperature range: +125°

Rail-to-rail operation

Typical power consumption: <0.01 μW

TTL/CMOS compatible inputs

ADG849YKSZ Applications

Mobile phones

Pocket PCs

Battery powered systems

Audio and video signal routing

Modems

PCMCIA Cards

Hard Disk Drive

Relay Replacement
