STTH6012W is an ultra-fast recovery rectifier diode in a DO-247-2 package, suitable for high-voltage, high-current power management and motor drive applications. This diode features a reverse breakdown voltage of 1.2 kV and a forward current rating of 60 A, with a reverse recovery time of just 125 ns, making it suitable for high-frequency switching circuits such as industrial power supplies, electric vehicle charging systems, inverters, and other applications.

STTH6012W Key Features

Reverse recovery time (trr): 125ns, suitable for high-frequency switching applications.

Low forward voltage drop (Vf): 2.25V @ 60A, reducing conduction losses.

Reverse voltage (Vr): 1200V (1.2kV), suitable for high-voltage circuits.

Forward current (Io): 60A (continuous), surge current (Ifsm) up to 400A.

Operating temperature range: -65°C to +175°C, suitable for harsh environments.

Compliant with RoHS standards, lead-free packaging, environmentally friendly.

Packaging optimisation: DO-247-2 through-hole packaging, excellent heat dissipation performance, suitable for high-power applications.

Technical Specifications

Model: STTH6012W

Manufacturer: STMicroelectronics

Type: Ultra-fast recovery rectifier diode

Reverse voltage (Vr): 1200V

Forward current (Io): 0A

Forward voltage drop (Vf): 2.25V @ 60A

Reverse recovery time (trr): 125ns

Reverse Leakage Current (Ir): 30 μA @ 1200V

Surge Current (Ifsm): 400A

Package: DO-247-2

Operating Temperature: -65°C to +175°C

Compliance Standards: RoHS, AEC-Q100 (for certain applications)

STTH6012W Applications

• AC-DC Converters

• DC-DC conversion stage in power supplies

• AC-DC converters

• Solar inverters

• Electric vehicle charging stations

• Telecommunications power supplies

• Uninterruptible power supplies (UPS)
