The TPS7A6333QPWPRQ1 is a low-dropout linear regulator designed for low-power applications with a quiescent current of less than 35µA. These devices feature an integrated programmable window watchdog and overcurrent protection, ensuring stable operation even when paired with low ESR ceramic output capacitors. Designers can set the output voltage using an external resistor. The low-voltage tracking feature allows the use of smaller input capacitors and may eliminate the need for a boost converter during cold start-up. Power-on reset delay is fixed (typical value 250µs) or can be set using an external capacitor. With these features, the TPS7A6333QPWPRQ1 device is ideal for power supply applications in various automotive applications.

TPS7A6333QPWPRQ1 Features

• Compliant with the AEC-Q100 standard for automotive applications:

– Temperature grade 1: -40°C to 125°C, TA

– Junction temperature range: -40°C to 150°C, TJ

• Low voltage drop:

– 300mV at IOUT = 150mA

• Wide input voltage range from 7V to 40V, with transient voltages up to 45V

• Maximum output current of 300mA

• Ultra-low quiescent current:

– IQUIESCENT = 35µA (typical) at light load

– ISLEEP < 2µA when EN = low level

• Fixed voltages of 3.3V and 5V, with an adjustable voltage range of 2.5V to 7V

• Integrated watchdog with fault/flag

• Maintains stability when used with low ESR ceramic output capacitors

• Integrated power-on reset:

– Programmable delay

– Open-drain reset output

• Integrated fault protection:

– Short-circuit and overcurrent protection

– Thermal shutdown

• Low input voltage tracking

• Thermally enhanced 14-pin HTSSOP-PWP package

TPS7A6333QPWPRQ1 Applications

• Automotive audio head units

• Headlights

• DC/DC converters

• Automotive central information displays
