CSD87312Q3E is a 30V common-source, dual N-channel device designed for adaptor/USB input protection. This SON 3.3 x 3.3mm device has low drain to drain on-resistance that minimizes losses and offers low component count for space constrained multi-cell battery charging applications.

Specifications Of CSD87312Q3E

Technology:MOSFET (Metal Oxide)

Configuration:2 N-Channel (Dual) Common Source

FET Feature:Logic Level Gate

Drain to Source Voltage (Vdss):30V

Current - Continuous Drain (Id) @ 25°C:27A

Rds On (Max) @ Id, Vgs:33mOhm @ 7A , 8V

Vgs(th) (Max) @ Id:1.3V @ 250µA

Gate Charge (Qg) (Max) @ Vgs:8.2nC @ 4.5V

Input Capacitance (Ciss) (Max) @ Vds:1250pF @ 15V

Power - Max:2.5W

Operating Temperature:-55°C ~ 150°C (TJ)

Features Of CSD87312Q3E

Common Source Connection

Ultra Low Drain to Drain On-Resistance

Space Saving SON 3.3 x 3.3mm Plastic Package

Optimized for 5V Gate Drive

Low Thermal Resistance

Avalanche Rated

Pb Free Terminal Plating

RoHS Compliant

Halogen Free

Applications Of CSD87312Q3E

Adaptor/USB Input Protection for Notebook PCs and Tablets
