The BSP613P is a P-channel enhancement mode small signal MOSFET from Infineon's SIPMOS® series, manufactured using trench (Trench) process technology. It is specifically designed for 60 V medium-voltage applications, 2.9 A-class load switching, reverse polarity protection, and high-side drive applications. The BSP613P is available in a PG-SOT223-4 (equivalent to SOT-223) surface-mount package and is AEC-Q101 certified, meeting automotive reliability requirements.

BSP613P Product Parameters

Channel Type: P-channel (Enhancement Mode)

Maximum Drain-Source Voltage (VDS): 60 V

Continuous Drain Current (ID): 2.9 A (Ta = 25°C)

Pulse Drain Current (IDM): 11.6 A

Gate-Source Voltage (VGS): ±20 V

Input Capacitance (Ciss): 715pF @ VDS = -25V

Gate Charge (Qg): 22nC @ VGS = -10V

Package: SOT-223-4 (with heat sink pad)

Compliance Standards: AEC-Q101, RoHS

BSP613P Features

Enhanced Mode

Normal Grade

Avalanche Rating

Fast Switching

dv/dt Rating

Lead-Free/Lead-Plated

RoHS Compliant, Halogen-Free

Automotive Standard Compliant

PPAP Supported

BSP613P Applications

Electronic Stability Control

Electric Power Steering (EPS)

Electric Vehicle Traction Inverter

Programmable Logic Controller (PLC)
