The DRV8305NPHPR is a gate driver integrated circuit (IC) designed for three-phase motor drive applications. The device provides three high-precision, temperature-compensated half-bridge drivers, each capable of driving a high-side and low-side N-channel MOSFET.

The charge pump driver supports low-voltage operation at a 100% duty cycle. The gate driver can also handle load dump pulses up to 45V.

The gate driver uses automatic handshaking during switching to prevent current breakdown. The device precisely senses the VDS of the high-side and low-side MOSFETs to protect the external MOSFETs during overcurrent conditions.

The DRV8305NPHPR provides three shunt amplifiers for precise current measurement, supporting gain-adjustable bidirectional current sensing.

The DRV8305NPHPR features an integrated regulator and controller to meet the power requirements of a microcontroller (MCU) or additional systems.

SPI provides detailed fault reports and flexible parameter settings, such as gain options for the shunt amplifiers, gate driver slew rate control, and multiple protection features.

DRV8305NPHPR Features

4.4V to 45V operating voltage range

1.25A/1A peak gate driver current

Programmable independent high-speed (HS)/low-speed (LS) switching rate/slope control

Supports 100% duty cycle charge pump gate driver

Three integrated shunt amplifiers

50mA integrated low-dropout regulator (LDO) (3.3V/5V options)

Supports control of 3 pulse width modulation (PWM) or 6 PWM inputs, with a maximum frequency of 200kHz

Built-in commutation table for single PWM applications

Programmable dead time

Metal-oxide-semiconductor field-effect transistor (MOSFET) breakdown protection

Programmable VDS protection for MOSFETs

Supports battery reverse protection

Supports 3.3V/5V digital interface

SPI interface

Protection features

VM under-voltage lockout (UVLO2)

Logic under-voltage (UVLO1)

Charge pump under-voltage (CPUVL)

Over-temperature warning and shutdown

Watchdog timer

Applications of DRV8305NPHPR

Three-phase brushless DC (BLDC) motors and permanent magnet synchronous motors (PMSM)

Continuous positive airway pressure (CPAP) and pumps

Robots and remote-controlled (RC) toys

Power tools

Industrial automation
