The L99PCU2F is a multi-channel intelligent power driver specifically designed for automotive electronic applications. The chip integrates multiple protection functions and diagnostic interfaces, making it suitable for automotive electronic control systems such as body control modules (BCM), electric seat adjustment, and window lift systems.

L99PCU2F Core Features

4 high-side drivers (up to 1.5A per channel)

4 low-side drivers (up to 1.5A per channel)

Overcurrent protection (OCP)

Overtemperature protection (OTP)

Short-circuit protection (SCP)

Undervoltage lockout (UVLO)

SPI interface, supporting real-time status monitoring

Fault diagnosis output (open-circuit/short-circuit detection)

Compliant with AEC-Q100 standard

Operating temperature range: -40°C to +150°C

Standby current as low as 10μA

3.3V/5V logic level compatible

L99PCU2F Typical Applications

Body electronics: door modules, seat adjustment, rearview mirror control

Lighting systems: LED drivers, headlight control

Comfort systems: sunroof control, air conditioning damper drivers

Technical specifications

Model: L99PCU2F

Operating voltage: 5.5V to 28V

Output current: 1.5A per channel

Communication interface: SPI

Protection features: OCP/OTP/SCP/UVLO

Operating temperature: -40°C to +150°C
