The AMC1350QDWVRQ1 is an automotive isolation amplifier. The output and input circuits of this amplifier are separated by isolation barriers with extremely strong anti-electromagnetic interference performance. This isolation barrier is certified to provide an enhanced electrical isolation of up to 5kVRMS, in compliance with VDE V 0884-11 and UL1577 standards, and can support an operating voltage of up to 1.5kVRMS.

The features of AMC1350QDWVRQ1

• Comply with the EC-Q100 standard for automotive applications:

-Temperature grade 1: -40 °C to +125°C, TA

Provide functional safety

- Documents that can assist in the design of functional safety systems

• Linear input voltage range: ±5V

• High input impedance: 1.25mΩ (typical value)

• Fixed gain: 0.4V /V

• Low DC error:

- Offset voltage error ±1.5mV (maximum value)

- Temperature drift: ±15µV/°C (maximum value)

- Gain error: ±0.2% (maximum value)

-Gain drift: ±35ppm/°C (maximum value)

-Nonlinearity ±0.02% (maximum value)

• High-side and low-side operating voltages: 3.3V or 5V

• High CMTI: 100kV/µs (min)

• Failure protection output

• Safety-related certifications:

-7070-VPK Enhanced isolation, in compliance with DIN VDE V0884-11:20117-01

-Compliant with UL1577 standard and with a 5000VRMS isolation of up to 1 minute

In addition, the AMC1350QDWVRQ1 can be used for isolated voltage sensing in the following applications:

-Traction inverter

-Car charger

-DC/DC converter

-DC charger for hybrid vehicles/electric vehicles
