The AMC0311DDWVR is a precision electrically isolated amplifier featuring a 2V high-impedance input, fixed gain, and differential output. The high-impedance input is optimised for connection to high-impedance resistive voltage dividers or other voltage sources with high output resistance. The AMC0311DDWVR outputs a differential signal proportional to the input voltage. The differential output is insensitive to ground drift, enabling long-distance transmission of the output signal.

AMC0311DDWVR Product Features:

Linear input voltage range: -0.1V to 2V

High input impedance: 1GΩ (typical)

Supply voltage range:

High side (VDD1): 3.0V to 5.5V

Low side (VDD2): 3.0V to 5.5V

Fixed gain: 1V/V

Differential output

Low DC error:

Offset voltage error: ±1mV (maximum)

Temperature drift: ±10µV/°C (maximum)

Gain error: ±0.25% (maximum)

Gain drift: ±40ppm/°C (maximum)

Non-linearity: 0.05% (maximum)

High CMTI: 50V/ns (minimum)

Low EMI: Compliant with CISPR-11 and CISPR-25 standards

AMC0311DDWVR Applications:

Motor drivers

Photovoltaic inverters

Server power supply units (PSU)

Electric vehicle charging stations
