The AMC0311SDWVR is a precise electrically isolated amplifier featuring a 2.25V high-impedance input, fixed gain and single-ended output. The high-impedance input is optimized for connections with high-impedance resistor voltage dividers or other voltage signal sources with high output resistance.

Main specifications

Number of channels: 1 Channel

Insulation voltage: 5 kVrms

Isolation type: Galvanic

GBP- Gain bandwidth product: 125 kHz

Ib - Input bias: 3 nA

Vos - Input bias voltage: 200 uV

Power supply voltage - Maximum: 5.5V

Power supply voltage - minimum: 3 V

Working power supply current: 4.4 mA, 4.8 mA

Operating temperature: -40 °C to + 105°C

Installation style: SMD/SMT

Package/Box: SOIC-8

Application field

AMC0311SDWVR is suitable for a variety of industrial applications, including:

Electric motor drive ‌

Photovoltaic inverter ‌

Server Power Supply Unit (PSU) ‌

Electric vehicle charging station ‌

These application fields benefit from their characteristics such as high input impedance, low DC error and low electromagnetic interference, ensuring the stability and reliability of the equipment.
