For picture reference, please see the specifications
< >

Commodity Model:SI8920BC-IPR

Trade Name:Isolation Amplifier

Brand:Skyworks

Particular Year:22+

Package:DIP-8

Delivery Date:New and Original

Stock: 11500pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Skyworks
Model
SI8920BC-IPR
Package
DIP-8
Describe
Isolated analog amplifier with +/-200 mV input

Product Description

SI8920BC-IPR is an electrically isolated analog amplifier. Low voltage differential input is very suitable for measuring the voltage across shunt resistors and is also applicable to any place where sensors must be isolated from the control system. The output is a differential analog signal amplified by 8.1x or 16.2x.


The extremely low signal delay of SI8920BC-IPR enables the control system to quickly respond to fault conditions or load changes. Low offset and gain drift ensure accuracy is maintained throughout the entire operating temperature range. The extremely high common mode transient immunity means that even in the presence of high-power switches in motor drive systems and inverters, SI8920BC-IPR can provide accurate measurements.


Main features of SI8920BC-IPR

•Low voltage differential input

• ± 100 mV and ± 200 mV options

•Low signal delay: 0.75 µ s

• Input offset: 0.2 mV

•Gain error:<0.5%

• Excellent drift specifications

•1 µ V/° C offset drift

•10 ppm/° C gain drift

• Nonlinear: 0.025% of full scale

•Low noise: 0.10 mVrms within a bandwidth of 100 kHz

• High common mode transient immunity: 75kV/µ s

• Compact packaging

•16 pin wide body SOIC

•8-pin surface mount DIP

•-40 to 125 ° C

•AEC-Q100

• Can provide automotive grade OPN

•PPAP document support that complies with AIAG standards

•IMDS and CAMDS lists support


SI8920BC-IPR Application Areas:

Automotive applications: Suitable for hybrid and electric vehicle traction inverters, AC, brushless, and DC motor control and drive, charging stations, etc.

Industrial applications: can be used for industrial and renewable energy inverters, variable frequency motor control in consumer white goods, isolated switch mode, and UPS power supply.
