The LTC6803HG-4 is a high-precision battery pack monitoring chip capable of monitoring the voltage and balancing functions of up to 12 series-connected lithium-ion or lead-acid battery packs. It features high-precision measurement, low power consumption, built-in passive battery balancing, and strong anti-interference capabilities, making it suitable for applications such as electric vehicles, energy storage systems, and uninterruptible power supplies that require high-precision battery management.

LTC6803HG-4 Features:

High-precision battery voltage measurement: measurement error range less than ±1.2mV.

Built-in passive battery balancing function: supports up to 20mA balancing current, helping to extend battery life.

Supports daisy-chain connection mode: allows multiple chips to be cascaded to monitor longer battery strings.

Configurable fault detection and alarm functions: Includes overvoltage, undervoltage, and communication errors.

Flexible operating mode selection: Includes low-power sleep mode to reduce current consumption during standby.

Built-in diagnostic functions: Can detect the operational status of its own hardware, enhancing system reliability and safety.

Robust noise immunity: Maintains high-precision measurement even in noisy electrical environments.

Flexible packaging options: Utilises a 44-pin SSOP package for easy integration into various electronic devices.

Wide operating voltage range: Operates within a voltage range of 2.5V to 5.5V, accommodating diverse power supply conditions.

Low-power design: Maximum power consumption is only 19mW, helping to reduce device energy consumption.

Input voltage range per channel: 0V to 5V, ensuring stable operation under different battery voltage conditions.

High measurement accuracy: Measurement accuracy is ±1.2mV, ensuring the accuracy of battery state estimation.

Wide temperature range: Operating temperature range is -40°C to +125°C, adapting to different environmental conditions.

High integration: Built-in 12-bit ADC, precision voltage reference, high-voltage input multiplexer, and serial interface simplify the design process.

LTC6803HG-4 Parameters:

Operating voltage range: 2.5V to 5.5V

Maximum power consumption: 19mW

Input voltage range per channel: 0V to 5V

Measurement accuracy: ±1.2mV

Communication interface: SPI

Operating temperature range: -40°C to +125°C

Package type: SSOP-44

LTC6803HG-4 Applications:

Electric and hybrid electric vehicles

High-power portable devices

Backup battery systems

Electric bicycles, motorcycles, and scooters
