Service Telephone:86-755-83294757
Trade Name:Battery Management
Brand:ADI
Particular Year:25+
Package:LQFP-48
Delivery Date:New and Original
Stock: 7500pcs
The LTC3300ILXE-1 is a Fault Protection Controller IC for transformer-based bi-directional active balancing of battery packs with multiple cells. The device integrates all relevant gate drive circuitry, high accuracy battery sensing, fault detection circuitry, and a rugged serial interface with built-in watchdog timer.
Each LTC3300ILXE-1 is capable of balancing up to six series-connected cells using an input common-mode voltage of up to 36V. Charge from any selected cell can be transferred back and forth between itself and 12 or more neighbouring cells at high efficiency.The LTC3300ILXE-1 has a unique level shifted SPI-compatible serial interface that allows multiple LTC3300ILXE-1 devices to be connected in series without the use of opto-couplers or isolators, thus enabling charge balancing for each of the cells in a long string of connected cells. The LTC3300ILXE-1 devices can be connected in series without the use of optocouplers or isolators to achieve charge balance for each cell in a long string of connected cells.
When multiple LTC3300ILXE-1 devices are connected in series, they are able to operate simultaneously, allowing all cells in a battery pack to be independently charge balanced at the same time. Fail-safe features include read-back capability, cyclic redundancy check (CRC) error detection, volt-second maximum on-time clamping, and overvoltage shutdown.
LTC3300ILXE-1 Features
Bidirectional synchronous flyback balancing of up to six series-connected Li-Ion or Li-FePO4 cells
Balancing current up to 10 A (external setting)
Seamless integration with LTC680x series multi-cell battery stack monitors
Bidirectional architecture for greater reduction in balancing time and power consumption
Up to 92% charge transfer efficiency
Stackable architecture supports systems above 1000V
Simple to use 2-winding transformer
1MHz daisy-chained serial interface with 4-bit CRC packet error checking
High noise tolerance serial communications
Multiple fault protection features
48-pin exposed pad LQFP package
AEC-Q100 certified for automotive applications
LTC3300ILXE-1 Applications
Electric Vehicles / Plug-in Hybrid Electric Vehicles (HEV)
High power UPS / grid energy storage systems
General purpose multi-cell battery packs
