BQ24715RGRR is a NVDC-1 synchronous battery charge controller with low quiescent current, high light load efficiency for 2S or 3S Li-ion battery charging applications, offering low component count.

The power path management allows the system to be regulated at battery voltage but does not drop below the programmable system minimum voltage.

BQ24715RGRR provides N-channel ACFET and RBFET drivers for the power path management. It also provides driver of the external P-channel battery FET. The loop compensation is fully integrated.

Features Of BQ24715RGRR

6-24V Input SMBus NVDC-1 2-3S Battery Charger Controller

System Instant-on Operation with No Battery or Deeply Discharged Battery

Ultra-Fast Transient Response of 100 µs

Ultra-Low Quiescent Current of 500 µA and High PFM Light Load Efficiency 80% at 20mA load to Meet Energy Star and ErP Lot6

Switching Frequency: 600kHz/800kHz/1MHz

Programmable System/Charge Voltage (16 mV/step), Input/Charge Current (64 mA/step) with High Accuracy

±0.5% Charge Voltage Regulation

±3% Input/Charge Current Regulation

±2% 40x Input/16x Discharge Current Monitor Output

Support Battery LEARN Function

Maximize CPU Performance with Deeply Discharged Battery or No Battery

Integrated NMOS ACFET and RBFET Driver

20-pin 3.5 × 3.5 mm2 QFN Package

Applications Of BQ24715RGRR

Ultrabook, Notebook, and Tablet PC

Industrial and Medical Equipment

Portable Equipment
