The TLV9152IDR is a family of 16V general purpose operational amplifiers. These devices offer excellent DC accuracy and AC performance, including rail-to-rail output, low offset voltage (±125µV, typical), low offset drift (±0.3µV/°C, typical), and a 4.5MHz bandwidth.

Convenient features such as wide differential input voltage range, high output current (±75mA), high slew rate (20V/µs), and low noise (10.5nV/√Hz) make the TLV915x a robust and low noise op amp for industrial applications.

The TLV9152IDR op amps are available in a standard package and are specified for temperatures from -40°C to 125°C. The TLV9152IDR op amps are available in a standard package and are designated for use in industrial applications.

Features - TLV9152IDR

- Low offset voltage: ±125µV

- Low offset voltage drift: ±0.3µV/°C

- Low noise: 10.5nV/√Hz at 1kHz

- High common mode rejection: 120dB

- Low bias current: ±10pA

- Rail-to-rail inputs and outputs

- Wide bandwidth: 4.5MHz GBW

- High-voltage swing rate: 20V/µs

- Low quiescent current: 560µA per amplifier

- Wide supply voltage: ±1.35V to ±8V, 2.7V to 16V

- Robust EMIRR performance: EMI/RFI filters on input pins

- Differential and common mode input voltage ranges on supply rails

 Specifications - TLV9152IDR

- Product Category: Operational Amplifiers - Op Amps

- Number of Channels: 2 Channel

- GBP - Gain Bandwidth Product: 4.5 MHz

- SR - Conversion Rate: 21 V/us

- Vos - Input Bias Voltage: 125 uV

- Ib - Input bias current: 10 pA

- Supply Voltage - Max: 16 V

- Supply voltage - min: 2.7 V

- Operating supply current: 560 uA

- Output current per channel: 75 mA

- CMRR - Common Mode Rejection Ratio: 125 dB

- en - Input voltage noise density: 10.8 nV/sqrt Hz

- Package / Case: SOIC-8

- Mounting style: SMD/SMT

- Shutdown: Shutdown

- Minimum operating temperature: - 40 C

- Maximum operating temperature: + 125 C

- Series: TLV9152

Applications - TLV9152IDR

- Professional microphone and wireless systems

- Multiplexed data acquisition systems

- Test and measurement equipment

- Factory automation and control

- High-side and low-side current detection
