Commodity Model:LTC4270BIUK

Trade Name:Power over Ethernet (PoE) Controller

Brand:ADI

Particular Year:21+

Package:QFN-52

Delivery Date:New and Original

Stock: 10000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
LTC4270BIUK
Package
QFN-52
Describe
12-Port PoE / PoE+ / LTPoE++ PSE Controller

Product Description

The LTC4270BIUK is a 12-port Power Sourcing Equipment (PSE) controller designed for use in Power over Ethernet (PoE) systems that comply with the IEEE 802.3at Type 1 and Type 2 specifications (high power). The transformer-isolated communication protocol replaces expensive optocouplers and complex isolated 3.3V power supplies, resulting in significant BOM cost savings. The LTC4270BIUK chip offers industry-low thermal dissipation through the use of low RDS(ON) external MOSFETs and 0.25Ω sense resistors.


Advanced power management features include a 12-bit per port current monitoring ADC, DAC programmable current limits, and universal fast shutdown for pre-selected ports. The Advanced Power Management host software is available with a free licence, and PD Discovery employs a proprietary dual-mode, 4-point detection mechanism that ensures superior protection against PD false detections. Mid-span PSE support is provided with a two-event classification capability and a 2s delay timer.


The LTC4270BIUK includes an I2C serial interface that operates at frequencies up to 1MHz. The LTC4270BIUK has a variety of power stages to provide up to 90W of PD power.


LTC4270BIUK Features

12 independent PSE channels

Compliant with IEEE 802.3at Type 1 and Type 2 standards

Chipset provides galvanic isolation

Reduced bill of materials (BOM) costs

Eliminates up to 6 high-speed optocouplers

Eliminates isolated 3.3V power supply

Low power consumption

0.25Ω detection resistance per channel

Very high reliability 4-point PD detection

Two-point applied voltage

Two-point applied current

VEE and VPORT monitoring

1s rolling IPORT averaging

Supports two and four pairs of output power

1MHz I2C compatible serial control interface

Three power levels are available

Class A - LTPoE++™: 38.7W to 90W

Class B - PoE+: 25.5W

Class C - PoE: 13W

Available in 52-pin 7mm x 8mm (LTC4270) package


LTC4270BIUK Applications

PoE PSE switches/routers

PoE PSE centre span
