Service Telephone:86-755-83294757
Trade Name:Clock Buffer
Brand:ON
Particular Year:24+
Package:QFN-16
Delivery Date:New and Original
Stock: 2000pcs
The NB6N11SMNG is a differential 1:2 clock or data receiver that accepts AnyLevelTM input signals: LVPECL, CML, LVCMOS, LVTTL, or LVDS, which will be converted to LVDS and distribute two copies of the same clock or data, operating at up to 2.0 GHz or 2.5 Gb/s, respectively.Therefore, the NB6N11S is ideal for SONET, GigE, Fibre Channel and other backplane applications. The NB6N11S is ideal for SONET, GigE, Fibre Channel, backplane, and other clock or data distribution applications.The NB6N11SMNG has a wide input common-mode range from GND + 50mV to VCC - 50mV.Combined with a 50-ohm internal termination resistor at the input, the NB6N11SMNG is ideally suited for converting a variety of differential or single-ended clock or data signals to 350 mV typical LVDS. The NB6N11SMNG is ideally suited for converting a variety of differential or single-ended clock or data signals to a typical LVDS output level of 350 mV. The NB6N11SMNG is functionally equivalent to the EP11, LVEP11, SG11, or 7L11M devices, and is available in a small 3mm X 3mm 16-QFN package.
NB6N11SMNG Features
Maximum Input Clock Frequency > 2.0 GHz
Maximum input data rate > 2.5 Gb/s
Maximum root-mean-square clock jitter of 1 ps
Typical 10 ps data-dependent jitter
380 ps typical propagation delay
120 ps typical rise and fall times
These devices are available in lead-free packages.
NB6N11SMNG Applications
High-Performance LVDS Clock and Data Distribution for ATE and Networking
NB6N11SMNG Product Attributes
Product Category: Clock Buffers
Number of Outputs: 2 Output
Propagation delay - max: 470 ps
Package / Case: QFN-16
Maximum input frequency: 2 GHz
Supply voltage-min: 3 V
Supply Voltage-Max: 3.6 V
Series: NB6N11S
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
