Commodity Model:IXGH28N60B3D1

Trade Name:IGBT Single Tube

Brand:IXYS

Particular Year:25+

Package:TO-247AD

Delivery Date:New and original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
IXYS
Model
IXGH28N60B3D1
Package
TO-247AD
Describe
Insulated gate bipolar transistor (IGBT) PT 600 V 66 A 190 W Through-hole TO-247AD

Product Description

The IXGH28N60B3D1 insulated gate bipolar transistor (IGBT) offers switching capability up to 150 kHz and a current range of 66A. The combination of high switching speed and low conduction loss provides power supply designers with a new high-value switching application option. This product has the following main parameters:

IGBT type: PT

Voltage - Emitter breakdown (maximum value) : 600 V

Current - Collector (Ic) (maximum value) : 66 A

Current-collector pulse (Icm) : 150 A

Vce(on) (maximum value) at different Vge and Ic: 1.8V @ 15V, 24A

Power - Maximum: 190 W

Switching energy: 340µJ (on), 650µJ (off)

Input type: Standard

Gate charge: 62 nC

Td (on/off) value at 25°C: 19ns/125ns

Test conditions: 400V, 24A, 10 ohms, 15V

Reverse recovery time (trr) : 25 ns

Operating temperature: -55°C to 150°C (TJ)

Installation type: Through hole

Packaging/Shell: TO-247-3


In addition, the IXGH28N60B3D1 transistor is suitable for a wide range of high-efficiency power supplies and electronic devices, especially in communication power supplies, industrial drives, medical devices, automotive electronics and flat panel displays ‌.
