The ADUM3402ARWZ is a four-channel digital isolator using Analog Devices iCoupler. These isolation devices combine high-speed CMOS with single-chip air-core transformer technology and offer outstanding performance characteristics over alternative devices such as optocouplers.

ADUM3402ARWZ Features

Enhanced system-level ESD protection, compliant with IEC 61000-4-x

Two-way communication

3 V/5 V Level Conversion

Operating temperature up to: 105 °C

High data rate: dc to 90 Mbps (NRZ)

Technical Parameters of ADUM3402ARWZ

Isolation voltage: 2500Vrms

Data rate: Up to 90Mbps (NRZ), with a maximum transmission delay of 100ns at 1Mbps

Common mode transient immunity (CMTI): 25kV/μs

Operating temperature range:-40 ℃ to + 105 ℃

Supply voltage: Supports 3.3 V and 5V dual supply voltages

Quiescent current: 1.4 mA maximum per channel at 0Mbps to 2Mbps under 5V operation; 0.9 mA max per channel at 0Mbps to 2Mbps at 3.3 V operation

ADUM3402ARWZ Application

Universal multi-channel isolation

SPI/Data Converter Isolation

RS-232/RS-422/RS-485 transceiver

Industrial Fieldbus Isolation
