The CDCS504TPWRQ1 device is an LVCMOS input clock buffer with selectable frequency multiplication.

The CDCS504TPWRQ1 has an output enable pin. The device accepts a 3.3V LVCMOS signal on the input. This input signal is processed by a phase-locked loop (PLL) whose output frequency is either equal to the input frequency or multiplied by a factor. In this way, the device can generate an output frequency between 2MHz and 108MHz. Separate control pins can be used to enable or disable the output. the CDCS504TPWRQ1 device operates in a 3.3V environment.

It features an operating temperature range of -40°C to 105°C and is available in an 8-pin TSSOP package.

Features Of CDCS504TPWRQ1

Compliant with automotive applications Standards

AEC-Q100 test guidelines with the following results:

Device Temperature Level 2: -40°C to 105°C ambient operating temperature range

Device Human Body Discharge Mode (HBM) Electrostatic Discharge (ESD) Classification Level H2

Device Component Charging Mode (CDM) ESD Classification Level C3B

Part of the Easy-to-Use Clock Generator Device Family

Clock multiplier with selectable output frequency

Frequency multiplication of x1 or x4 can be selected using an external control pin

Output disable via control pin

Single 3.3V device power supply

Wide temperature range: -40°C to 105°C

Space-saving 8-pin thin small form factor (TSSOP) package

CDCS504TPWRQ1 Applications

Automotive applications (clock multiplication required)
