The 9FGL6241AP202NDGI is an intelligent buffer/clock generator specifically designed for single/dual-port nVME SSDS. It features the following key parameters:

PLL: Yes

Main use: PCI Express (PCIe)

Input: Clock

Output: LP-HCSL, LVCMOS

Number of circuits: 1

Ratio - Input: Output: 3:2

Differential - Input: Output: Yes/Yes

Frequency - Maximum value: 100MHz

Voltage - Power supply: 1.71V to 1.89V, 2.375V to 3.465V, 3.135V

Operating temperature: -40°C to 85°C (TA)

Installation type: Surface mount type

Package/Housing: 28-VFQFN

The 9FGL6241AP202NDGI supports both general-purpose (CC) and independent reference (IR) clock architectures, making it highly suitable for U.2 and M.2 forms. This device can also be used in PCIe master/slave and clock multiplexing applications, with an integrated clock generator serving as the third input channel.

Typical applications

▪ 1 × 4 and 2 × 2 nVME SSDS

▪ 3:2 PCIe clock multiplexing
