The 9FGL6241AP302NDGI is an intelligent buffer/clock generator specifically designed for single-port and dual-port nVME solid-state drives. It supports both universal (CC) and independent reference (IR) clock architectures, making it highly suitable for U.2 and M.2 forms. The 9FGL6241AP302NDGI can also be used in PCIe master/slave and clock multiplexing applications, with an integrated clock generator serving as the third input channel.

Key parameters

PLL: Yes

Main use: PCI Express (PCIe)

Input: Clock

Output: LP-HCSL, LVCMOS

Number of circuits: 1

Ratio - Input: Output: 3:2

Differential - Input: Output: Yes/Yes

Frequency - Maximum value: 100MHz

Voltage - Power supply: 1.71V to 1.89V, 2.375V to 3.465V, 3.135V

Operating temperature: -40°C to 85°C (TA)

Installation type: Surface mount type

Package/Housing: 28-VFQFN

Typical applications

▪ 1 × 4 and 2 × 2 nVME SSDS

▪ 3:2 PCIe clock multiplexing
