Trade Name:Digital Isolator
Brand:ADI
Particular Year:25+
Package:BGA-24
Delivery Date:New and Original
Stock: 3000pcs
LTM2894IY: 7500Vrms, 1 Channel, USB Digital Isolator, BGA-24
Basic Information:
Model: LTM2894IY
Package: BGA-24
Type: USB Digital Isolator
OVERVIEW: The LTM2894IY is a complete current-isolated μModule® mini-module) transceiver compatible with the USB 2.0 specification.
Applications:
- Isolated USB interface
- Host, hub or device isolation
- Industrial/Medical Data Acquisition
LTM2894IY Product Features:
Isolated USB Transceiver: 7500VRMS (for 1 minute)
Pending UL-CSA approval
Enhanced insulation
Compatible with USB 2.0 full-speed and low-speed specifications
Auto configuration of bus speed
4.4V to 36V VBUS and VBUS2 operating range
3.3V LDO output power signal references VLO and VLO2
Withstands high common-mode transients: 50kV/μs
±20kV HBM ESD: on USB interface pins
1414VPEAK Maximum Continuous Operating Voltage
17.4mm Creepage distance
22mm x 6.25mm surface-mount BGA package
Model
Brand
Package
Quantity
Describe
ADI
SOIC-16
4000
Quad-channel digital isolator with enhanced system-level ESD reliability
TI
SOIC-16
3000
Automotive-grade four-channel enhanced digital isolator with integrated 420kHz transformer driver
TI
SOIC-16
3000
Automotive-grade four-channel enhanced digital isolator with integrated 160kHz transformer driver
ADI
SSOP-20
5000
Compact, four-channel, 3.75 KV RMS digital isolator (3/1 channel directional)
A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.
A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.
A: at present, our self-employed brands TI,ST,ADI,NXP,LATTICE,CYPRESS,INFINEON,XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.
A: You can inquire through the website, or by phone and email.
A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.
A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
The full name of Analog Devices is Analog Devices, Inc. (ADI). As an outstanding supplier specializing in semiconductor sensors and signal processing ICs, adi regards innovation, performance and excellence as the cultural pillars of the company and ha…
AD9279BBCZ
The AD9279BBCZ supports medical ultrasound and automotive radar applications and is specifically designed for low cost, low power consumption, small size and ease of use. It is equipped with an eight-channel variable gain amplifier (VGA), a low-noise …AD9278BBCZ
The AD9278BBCZ is designed for low cost, low power, small size and easy to use applications. It is equipped with an eight-channel variable gain amplifier (VGA), a low-noise preamplifier (LNA), an anti-aliasing filter (AAF), a 12-bit 10 MSPS to 65 MSPS…AD8285WBCPZ
The AD8285WBCPZ is designed for applications that require low cost, low power consumption, small size and ease of use. It is equipped with a 4-channel low-noise preamplifier (LNA), a programmable gain amplifier (PGA) and an anti-aliasing filter (AAF),…AD5648BRUZ-2
The AD5648BRUZ-2 is a low-power, eight-channel, 14-bit, buffered voltage output DAC, powered by a single 2.7V to 5.5V power supply, and monotonicity is guaranteed through design. The AD5648BRUZ-2 is equipped with a 2.5V, 5ppm /C reference voltage sour…AD5360BSTZ
The AD5360BSTZ is a 16-channel, 16-bit buffered voltage output digital-to-analog converter (DAC) in a 52-pin LQFP package . This device is equipped with 16 16-bit Dacs built-in, providing a buffer voltage output with a range four times the reference…AD5765CSUZ
The AD5765CSUZ is a four-channel, 16-bit, serial input, bipolar voltage output digital-to-analog converter (DAC) with an operating voltage range of 4.75V to 5.25V and a nominal full-scale output range of 4.096V. The AD5765CSUZ is equipped with an i…Contact Number:86-755-83294757
