The TL972IDGKR is a dual operational amplifier operating at voltages as low as ±1.35 V with rail-to-rail output signal swing.The characteristics of the TL972IDGKR make it particularly suitable for portable and battery-powered devices. Extremely low noise and low distortion characteristics make the TL97x ideal for audio preamplification.

Product Attributes (TL972IDGKR)

Manufacturer: Texas Instruments

Product Category: Operational Amplifiers - Op Amps

Number of Channels: 2 Channel

GBP - Gain Bandwidth Product: 12 MHz

SR - Conversion Rate : 5 V/us

Vos - Input Bias Voltage: 4 mV

Ib - Input bias current: 750 nA

Supply voltage - max: 12 V

Supply voltage - min: 2.7 V

Operating supply current: 2 mA

Output current per channel: 80 mA

CMRR - Common Mode Rejection Ratio: 85 dB

en - Input voltage noise density: 4 nV/sqrt Hz

Package / Case: VSSOP-8

Mounting Style: SMD/SMT

Shutdown: No Shutdown

Minimum operating temperature: - 40 C

Maximum Operating Temperature: + 125 C

Series: TL972

Dual Supply Voltage: +/- 3 V, +/- 5 V

Height: 0.97 mm

Length: 3 mm

Maximum Dual Supply Voltage: +/- 6 V

Minimum dual supply voltage: +/- 1.35 V

Operating supply voltage: 2.7 V to 12 V, +/- 1.35 V to +/- 6 V

Output Type: Rail-to-Rail

Power Supply Type: Single, Dual

Voltage Gain dB: 80 dB

Width: 3 mm

Unit weight: 26.500 mg
