Commodity Model:ADUM240E1BRWZ

Trade Name:Digital Isolators

Brand:ADI

Particular Year:25+

Package:SOIC-16

Delivery Date:New and original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
ADI
Model
ADUM240E1BRWZ
Package
SOIC-16
Describe
5kV RMS four-channel digital isolator, output enabled (4/0 channel directivity)

Product Description

The ADUM240E1BRWZ is a four-channel digital isolator using Analog Devices' iCoupler® technology. It is suitable for applications that require high-speed data transmission and strong isolation. The ADUM240E1BRWZ isolation device combines high-speed, complementary metal-oxide semiconductor (CMOS) with single-chip air-core transformer technology, offering outstanding performance characteristics over alternative devices such as optocouplers and other integrated couplers.


The ADUM240E1BRWZ has a maximum propagation delay of 13 ns and a pulse width distortion of less than 3 ns at 5 V. Has strict 3.0ns (maximum) channel matching.


Features

High common-mode transient immunity of the ADUM240E1BRWZ: 100 kV/µs

High immunity to radiation and conduction noise

Low propagation delay

13 ns (Max., 5 V)

15 ns (Max., 1.8V)

Maximum guaranteed data rate: 150 Mbps

Safety and Regulatory Certification (pending application)

UL Certification: 5000 V rms per minute, according to UL 1577

CSA Component Acceptance Notice 5A

VDE Certificate of conformity

DIN V VDE V 0884-10 (VDE V 0884-10):2006-12

VIORM = 849 V peak

Enhanced surge isolation voltage: 8000 V peak

CQC certification in line with GB4943.1-2011

Backward compatibility

ADuM240E1 ADuM241E1 / ADuM242E1 pin compatible ADuM2400 / ADuM2401 / ADuM2402

Low dynamic power consumption

1.8V to 5V level conversion

Operating temperature up to 125℃

Fail-safe High or low option

RoHS compliant 16-pin SOIC package

The ADUM240E1BRWZ device is certified for automotive applications


Application of ADUM240E1BRWZ isolator

Universal multichannel isolation

Serial Peripheral Interface (SPI)/ data converter isolation

Industrial fieldbus isolation


Associated Products

Model

Brand

Package

Quantity

Describe

ISO6520FREUR

TI

VSON-8

2000

General Purpose Dual-Channel Functional Isolators

ADUM121N1BRZ

ADI

8-SOIC

2000

3.0 kVrms Dual-Channel Digital Isolators

ISO7721QDRQ1

TI

SOIC-8

10000

High EMC performance automotive dual channel, 1/1, enhanced digital isolator

ISO1540DR

TI

SOIC-8

5000

I2C Digital Isolator 2500 Vrms 2 Channels 1 Mbps 25 kV/µs CMTI 8-SOIC (0.154", 3.90 mm wide)

ADUM1200CRZ

ADI

SOIC-8

10000

Dual-channel digital isolator (2/0 channel directionality)

ADUM1201CRZ

ADI

SOIC-8

10000

Dual-channel digital isolator (1/1 channel directionality)

ISO1176TDWR

TI

SOIC-16

6000

RS422, RS485 Digital Isolator 2500 Vrms 3 Channels 40 Mbps 25 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)

ADUM1401CRWZ

ADI

SOIC-16

13000

Four-channel digital isolator (3/1 channel directionality)

ADUM2250ARWZ

ADI

SOIC-16

6000

I2C Digital Isolator 5000 Vrms 2 Channels 1 Mbps 25 kV/µs CMTI 16-SOIC (0.295", 7.50 mm wide)

ISOW7842FDWER

TI

SOIC-16

2000

High-Performance 5000 VRMS Reinforced Quad-Channel Digital Isolators
