The BTS3405G is a single-channel, low-side power switch in a PG-DSO-8-25 package that provides embedded protection. The device consists of two independent monolithic ICs. Each IC features an N-channel power MOSFET transistor and additional protection circuitry.

BTS3405G Device Specifications.

Product Category: Power Switch ICs - Power Distribution

Current Limit: 600 mA

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 40 C

Humidity Sensitivity: Yes

Mounting Style: SMD/SMT

Number of Outputs: 2 Outputs

Idle time - max: 45 us

On-resistance - max: 700 mOhms

Runtime-Max: 38 us

Output current: 350 mA

Package / Case: SOIC-8

Pd-Power dissipation: 780 mW

Product: Power Switches

Product Type: Power Switch ICs - Power Distribution

Qualification: AEC-Q100

Series: HITFET

Factory Package Quantity: 2500

Sub Category: Switch ICs

Supply Voltage - Max: 10 V

Supply Voltage - Min: - 200 mV

Trade Name: HITFET

Type: Low Side

Potential Applications

Dual channel

Protected automotive

Relay Drivers

Application Areas

48 V Battery Management System (BMS)

Secondary Power Distribution Centre (PDC)

Car Body Control Modules (BCM)

Universal Motor Drives - Variable Frequency Transformers
