The ECMF04-4HSWM10 is a highly integrated common mode filter designed to suppress EMI/RFI common mode noise on high speed differential serial buses such as HDMI Full HD, MIPI, Display Port and other high speed serial interfaces.

With a very large differential bandwidth, the device complies with these standards and protects and filters both differential channels.

Product Features

Very large differential bandwidth for HDMI Full HD, MIPI, USB2.0, USB3.2 Gen 1, Display Port and other high-speed serial interfaces

High common mode attenuation at WLAN frequencies:

28 dB at 2.4 GHz, -16 dB at 5.0 GHz

Very good attenuation at LTE, GSM and GPS frequencies

Large bandwidth: 4.2 GHz

Small PCB footprint

Thin package for compact applications: up to 0.55 mm

Significant reduction of parasitic components through integration

RoHS package

IEC 61000-4-2, Class 4:

±15 kV (air discharge)

±8 kV (contact discharge)

Product Specifications

Filter Type: Signal Line

Number of lines: 4

Current Rating (Max): 100mA

DC Resistance (DCR) (Max): 5 Ohms (Typ)

Operating Temperature: -40°C ~ 85°C

Features: TVS Diode ESD Protection

Mounting Type: Surface Mount

Size/Dimensions: 0.102‘ L x 0.053’ W (2.60mm x 1.35mm)

Height (Max): 0.022’ (0.55mm)

Package / Case: 10-UFDFN

Product Applications

Set-top boxes

Game consoles

Portable devices
