LDL40PU33RY is a high accuracy voltage regulator designed to be directly connected to a car battery in automotive applications or a generic battery used in industrial applications. Extended input voltage up to 40 V makes the device able to support a load dump transient, which is typical in automotive systems. Ultra-low quiescent current at light load increases the battery operation lifetime in always-on-standby systems.

Feature Of LDL40PU33RY

AEC-Q100 grade 1 qualified

Operating temperature range: -40 °C < TJ < 150 °C

Input voltage from 3.3 V to 40 V

Dropout voltage (700 mV typ. at 200 mA load)

Low ground current (2 μA typ. at no load)

Output voltage: 3.3 V, 5.0 V, or ADJ from 1.2 V to 12 V

Output voltage tolerance: ±2.5% overtemperature, 0.5% at 25 °C

200 mA guaranteed output current

Power Good for fixed versions

Logic-controlled electronic shutdown

Internal current limit

Thermal shutdown

Output active discharge function

DFN6 (2 x 2) WF package

Applications Of LDL40PU33RY

EV powertrain

Always-on battery connected application

Infotainment and instrument cluster

ADAS
